Iteco iWash Max E 500 Electric

Iteco iWash Truck & Bus Wash features and benefits

Iteco Washing Systems pride themselves on creating a robust no frills machine that does the job without compromising on quality. The steel framework and solid design is paired with fantastic ease of use that operators young and old very quickly get to grips with.

Watch the video here

The Features
  • Brush tilt inclination (up to 20 degree) system allows the iWash to clean angled sides without compromising stability or performance.
  • Scientifically calculated, weight distribution vs height vs downward force, to increase static / maneuverable stability therefore not needing an external support frame.
  • Super high-density corner wheels (not castors), that can comfortably handle a less than perfect concrete wash bay floor, allowing for smooth and easy control and machine operation.
  • The battery option takes 8 hours to charge with a 5-6 hour running time.
  • Driven by a powerful hydraulic traction drive, this direct drive to the brush increases reliability and reduces bearing wear, running and maintenance costs.
  • Self-propelled drive wheel with steering yoke, allows you to just guide with ease the machine around a vehicle without the need to push, pull, drag, or scrape.
  • A perfectly clean vehicle in under 10 minutes, with the smallest amount of training.
  • An extra-large 500lt water tank and a separate detergent tank with no trailing hoses or cables. This improves safety by allowing hassle-free cleaning independent of fixed utilities.
  • No additional groundworks are needed for installation into your wash bay and no plant room work required therefore no expensive electrical supplies to connect or setting up costs.

Technical Data

Engine   Electric 24 V
Engine Fuel  Battery 24 V
Transmission  Hydraulic
Forward travel  Variable speed
Consumption  40-80 Amp/h
Start  Electric
Water tank capacity  500 litres – 110 UK gal
Detergent tank capacity  10 litres – 2,2 UK gal
Water consumption  25 litres/min- 5,5 UK gal/min
Water pressure on brush  3 Bar
Max. water pressure  3 Bar
Hydraulic fluid tank  10 litres- 2,2 UK gal
Max. brush inclination  15-20°
Brush diameter  1000 mm – 40 in
Weight  600 kg – 1323 Lbs
Overall Dimensions  1420×2290 mm h.4250 mm – 56×90 in h. 170 in



Brand

Iteco Washing Systems
